Chassis Setup
ThischaptercontainsinstructionsonsettinguptheK6chassis.
Electrical Hazard: Only qualified personnel should perform installation procedures.
Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes
Personal vorgenommen werden.
For information about... Refer to page...
Required Tools 3-2
Unpacking the K Chassis 3-2
Installing the K Chassis 3-3
Attaching the Electrostatic Discharge Wrist Strap 3-12
Installing and Removing a Power Supply 3-12
Installing and Removing a Fan Tray 3-16
Installing and Removing the Fabric Card 3-18
Installing and Removing a Line Card 3-22
Connecting Power 3-26
Connecting to the Fabric Card COM Port for Local Management 3-27
Connecting the Fabric Card and Line Card to the Network 3-29
Connecting to the Fabric Card USB Port 3-32
Changing the Mode of the Line Card RJ45 Ports 3-33
Completing the Installation 3-33
Important Notice
Read the Release Notes specific to the firmware image running in the chassis to check for any
exceptions to the supported features and operation documented in this guide.
