K-AC-PS-1400W Power Supply LEDs
TherearetwoLEDsoneachK‐AC‐PS‐1400Wpowersupply:aDCOKLEDindicatingthe
operationalstatusofoutgoingpowerandanACOKLEDindicatingincomingAClinevoltageis
sufficientorhasfallenbelowoperationallimits.RefertoFigure 4‐4forthelocationofthepower

supplyLEDs.Table 4‐5describesthedifferentstatesofthepowersupplyLEDs.
Figure 4-4 K-AC-PS-1400W Power Supply LEDs
1 AC OK LED 2 DC OK LED
Table 4-5 K-AC-PS-1400W Power Supply LED Status Definitions
LED LED Color Status
AC OK Green Sufficient AC power supply (influx)
Off Power supply malfunctioning
DC OK Green Power supply successfully providing 12 VDC to the system.
Off Power supply malfunctioning or unplugged.
