Installing the K Chassis
Enterasys K-Series K6 Chassis Hardware Installation Guide 3-7
Mid-Mounting a K Chassis
ToinstalltheK6chassisinarackusingthemid‐mountingbrackets:
1. Liftthechassisandslideitallthewayintotherackuntilthemid‐mountingbracketsare
againstthefrontoftherackposts.
2. Use6screws(3perside)tosecurethechassistotherack,
startingwiththebottomholesand
workingtowardthetopofthechassis.SeeFigure 3‐4.
Figure 3-4 Mid-Mounting the K6 Chassis in a Rack
Note: You must install the mid-mounting brackets on the K6 chassis before installing the K6 chassis
in the rack. See “Installing the Mid-mount Brackets” on page 3-4.
Warning: To help prevent personal injury, at least two people are required to lift the chassis into
the rack.
Advertencia: Para ayudar a prevenir alguna lesión personal , al menos dos personas son
requeridas para levantar el chasis y meterlo al rack.
Warnhinweis: Zum Schutz vor körperlichen Schäden, sollten sie mit min. zwei Personen das
Chassis in das Rack heben.
Note: Refer to Table A-4 on page A-2 for recommended torque values to use when installing the K6
chassis using standard threaded fastener machine screws and bolts.
