K6-FAN Fan Tray Specifications
A-2 Specifications and Regulatory Compliance
K6-FAN Fan Tray Specifications
Fabric Card Specifications
RefertothedatasheetforthespecificationsofthecurrentlyavailableK‐Seriesfabriccards:
http://www.enterasys.com/company/literature/k‐ds.pdf
Line Card Specifications
RefertothedatasheetforthespecificationsofthecurrentlyavailableK‐Serieslinecards:
http://www.enterasys.com/company/literature/k‐ds.pdf
Torque Values
Table A‐4describestherecommendedtorquevaluestousewhenusingstandardthreaded
fastenermachinescrewsand bolts.
Table A-3 K6-FAN Fan Tray Specifications
Item Specification
Weight .98 kg (2.15 lb)
Table A-4 Recommended Torque Values by Screw Size
Screw Size Torque in Pounds Bit Size
English Metric -%5 Nominal +%5
N/A N/A 1.42 1.5 1.57 0
2 – 56 1.5 2.85 3.0 3.15 0
4 – 40 2.5 4.75 5.0 5.25 0/1
6 – 32 3.5 8.55 9.0 9.45 1
8 – 32 4.5 17.10 18.0 18.90 2
10 – 32 5 30.40 32.0 33.60 2
1/4 – 20 6.5 63.65 67.0 70.35 3
