Installing and Removing a Line Card
Enterasys K-Series K6 Chassis Hardware Installation Guide 3-25
Removing a Line Card
1. PresstheOFFLINEbuttonandwaitfortheSTATU SLEDtochangecolor.SeeFigure 3‐24.
Figure 3-24 Line Card Offline Button
2. Loosenthecaptivescrewonthelinecard’sejectorhandle.
3. Openthelinecardejectorhandletoa45° angle.SeeFigure 3‐25.
Figure 3-25 Disengaging the Line Card Ejector Handle
1 OFFLINE button 2 STATUS LED
1 Captive screw
