Installing and Removing a Power Supply
Enterasys K-Series K6 Chassis Hardware Installation Guide 3-13
TheN+1methodprotectstheK6chassisagainstthefailureofasinglepowersupplyalthoughnot
againstanoutagebythatsource.Inaschemewherethreepowersuppliesareinstalled,youcan
assignallthreepowersuppliestoonesource.Thisisthemostcommonapproachto
powersupply
planning.
Alternately,the1+1methodhastheadvantageofprotectingtheK6chassisagainstanoutageby
oneofthepowersourcesaswellasthefailureofoneorasmanyashalfofyourpowersupplies.
However,thismethodrequireseitherabackupbatteryor
anotherpowersourceseparatefromthe
firstpowersource.
ThenumberofpowersuppliesrequiredinaK6chassisisdeterminedbythenumberandtypesof
linecardsinstalledinthechassis.
Unpacking a Power Supply
TheK‐AC‐PS‐1400WpowersupplymodulesareshippedinboxesseparatefromtheK‐Series
chassis.Tounpackapowersupply:
1. Unpackthepowersupplybyremovingitfromtheshippingboxandslidingthetwofoamend
capsofftheunit.
Savetheshippingboxandmaterialsin
theeventtheunitmustbereshipped.
2. Verifythecontents oftheboxusingTable 3‐2asappropriate.
3. Removethepowersupplyfromitsprotectiveplasticbag.
4. Examinethepowersupplycarefully,checkingfordamage.
Ifanydamageisnoted,DONOTinstallthepowersupply.ContactEnterasysNetworks
immediately.Referto
“GettingHelp”onpage xviifordetails.
Installing a Power Supply
YoumustinstallatleastoneK‐AC‐PS‐1400WpowersupplyintheK6chassis.Dependingonyour
moduleconfiguration,onepowersupplymayprovidesufficientpowertothechassis,but
multiplepowersuppliescanbeinstalledtoprovidearedundant,loadsha ringpowersource.
WhenyoureceiveyourK6
chassis,acoverplatewillbeinplaceoverpowersupplyslotsPS2,PS3,
andPS4.
ThepowersuppliesmustbeinstalledintheslotslabeledPS1,PS2,PS3,andPS4atthebottomof
thechassis.Ifyouintendtoinstallasinglepowersupply,youmustinstallitin
thepowersupply
slotlabeledPS1.
ToinstalltheK‐AC‐PS‐1400Wpowersupplies:
1. Attachtheanti‐staticwriststrapasdescribedin“AttachingtheElectrostaticDischargeWrist
Strap”onpage 3‐12beforehandlingthepowersupply.
Table 3-2 Contents of K-AC-PS-1400W Power Supply Carton
Item Quantity
K-AC-PS-1400W power supply 1
Type of power cord is dependent on country of installation.
For USA shipments: NEMA Power Cord 5-15, C13, R/A, SHLD
Each K-AC-PS-1400W power supply accepts (X) IEC320 C13 power cord plugs.
1
Power cord clip assembly 1
NOTICE Card 1
