Connecting the Fabric Card and Line Card to the Network
Enterasys K-Series K6 Chassis Hardware Installation Guide 3-31
Preparation
Beforeinstallingthepluggabletransceiver, proceedasfollows:
1. PutontheantistaticwriststrapandplugthecablefromtheantistaticwriststrapintotheESD
groundingreceptacleattheupperrightcornerofthechassisbeforeremovingthepluggable
transceiverfromtheanti‐staticpackaging.Refertotheinstructionsin
theanti‐staticwrist
strappackage.
2. Removethepluggabletransceiverfromthepackaging.
3. Ifthereisaprotectivedustcoveronthepluggabletransceiver,donotremoveitatthistime.
Installing the Pluggable Transceiver
ToinstallanSFPorSFP+pluggabletransceiverinaK‐Serieslinecardorfabriccard:
1. Holdthepluggabletransceiversothattheconnectorwillseatproperly.
2. Carefullyalignthepluggabletransceiverwiththeport.
3. Pushthepluggabletransceiverintotheportuntilthepluggabletransceiverclicksandlocks
intoplace.
Caution: Carefully follow the instructions in this manual to avoid damaging the SFP, SFP+, and
module.
The SFP, SFP+, and module are sensitive to static discharges. Use an antistatic wrist strap and
observe all static precautions during this procedure. Failure to do so could result in damage to the
SFP, SFP+, and module. Always leave the SFP or SFP+ in the antistatic bag or an equivalent
antistatic container when not installed.
Precaución: Siga las instrucciones del manual para no dañar el SFP, SFP+ ni el módulo, puesto
que son muy sensible a las descargas de electricidad estática.
Utilice la pulsera antiestática y tome todas las precauciones necesarias durante este
procedimiento. Si no lo hace, podría dañar el SFP, SFP+ o el módulo. Mientras no esté instalado,
mantenga el SFP o SFP+ en su bolsa antiestática o en cualquier otro recipiente antiestático.
