Micro-USB Port
Enterasys S-Series Stand Alone (SSA) Hardware Installation Guide 1-3
see “Reversing the Fan Module Air Flow” on page 2-5 for details about how to reverse the fan
module air flow.
The SSA fan modules are both field replaceable and hot swappable. For information on how to
replace SSA fan modules, see “Replacing the SSA Fan Module” on page 3-6.
Micro-USB Port
The micro-USB port is provided for local file transfer.
Management
You can manage the SSA switch either in-band or out-of-band. In-band remote management is
possible using the Enterasys Networks’ NetSight
®
management application or the command line
interface (CLI) via Telnet. Out-of-band management is provided through the RJ45 COM
(Communication) port on the front panel using a PC, a VT terminal, or a VT terminal emulator.
For more information, see “Connecting to the Network” on page 2-14.
Virtual Switch Bonding
For data center redundancy, you can configure two co-located SSA chassis to operate as a single
logical chassis (a virtual switch bonded chassis) managed by one IP address. Connect the chassis
to each other by using at least two 10G ports on each SSA chassis.
Note: For virtual switch bonding configuration details, see the Enterasys S-Series Configuration
Guide.
