Contents of Mounting Kit
C-2 Optional Rack Mount Rail Kit Installation
Contents of Mounting Kit
Table C-1 lists the contents of the SSA-FB-MOUNTKIT mounting kit.
Installation Site Requirements
If you plan to cable your SSA switch with SFP+ pluggable transceivers, you may need to have 3–4
inches of clearance on the switch I/O port side of the SSA switch.
See Appendix E, Environmental Guidelines for environmental guidelines relating to the SSA
switch installation.
The installation site must be within reach of the network cabling and meet the requirements listed
below:
• Appropriate grounded power receptacles must be located within 7 feet of the site.
• A temperature of between 5°C (41°F) and 40°C (104°F) must be maintained at the installation
site with fluctuations of less than 10°C (18°F) per hour.
For more information about flat surface installation or rack installation using the mounting
brackets installed on the SSA switch, see “Installation” on page 2-1.
Table C-1 Contents of SSA-FB-MOUNTKIT
Item Number
Left and right rails and extensions assemblies 2
Adapter plates 2
Mid-Brackets 2
6-32 flat head screws 6
10-32 pan head screws (black) 2
10-32 cage nuts 2
Note: The SSA-FB-MOUNTKIT mounting kit does not include rack screws. You must provide
screws or fasteners appropriate to your rack for securing the rails and the S-Series chassis in the
equipment rack. Each procedure in this guide specifies the number of rack screws that you must
provide.
Caution: To ensure proper ventilation and prevent overheating, leave a minimum clearance space
of 5.1 cm (2.0 in.) at the front and rear of the device.
Precaución: Para asegurar una buena ventilación y evitar que el sistema se sobrecaliente, deje un
espacio mínimo de 5.1 cm (2 pulgadas) con respecto el anverso y reverso del aparato.
Warning: Before rack-mounting the device, ensure that the rack can support it without
compromising stability. Otherwise, personal injury and/or equipment damage may result.
Advertencia. Antes de montar el equipo en el rack, asegurarse que el rack puede soportar su peso
sin comprometer su propia estabilidad, de otra forma, daño personal o del equipo puede ocurrir.
Warnhinweis: Überzeugen Sie sich vor dem Einbau des Gerätes in das Rack von dessen
Stabilität, ansonsten könnten Personenschäden oder Schäden am Gerät die Folge sein.
Avertissements: Avant de monter l'appareil sur le bâti, assurez-vous que l'étagère peut en
supporter le poids sans en compromettre la stabilité. Cela pourrait, dans le cas contraire, entraîner
des blessures ou des dommages au matériel.
