Pluggable Transceiver Specifications
A-2 Specifications
Pluggable Transceiver Specifications
For SFP and SFP+ transceiver specifications, refer to the datasheet at the following URL:
http://www.enterasys.com/products/transceivers-ds.pdf
COM Port Pinout Assignments
The COM port is an RJ45 communications port for local access to local management. Refer to the
table below for the COM port pin assignments.
SSA-FB-AC-PS-A and SSA-FB-AC-PS-B (Power Supplies)
Input Frequency 50 to 60 Hz
Input (Voltage/Current) at Output Power 100 to 240 V AC: 5.29 to 2.2A at 450 watts
Approximate Weight 0.86 kg (1.90 lb)
Environmental
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -30°C to 73°C (-22°F to 164°F)
Operating Relative Humidity 5% to 95% (non-condensing)
Table A-2 Specifications (continued)
Item Specification
Table A-3 COM Port Pin Assignments
Pin Signal Name Input/Output
1 Transmit Data (XMT) Output
2 Data Carrier Detect (DCD) Output
3 Data Set Ready (DSR) Input
4 Receive Data (RCV) Input
5 Signal Ground (GND) NA
6 Data Terminal Ready (DTR) Output
7 Request to Send (RTS) Input
8 Clear to Send (CTS) NA
