Installation Site Requirements
2-2 Installation
Installation Site Requirements
You need to have 3–4 inches of clearance on the switch I/O port side of the SSA switch depending
upon the cabling used.
See Appendix E, Environmental Guidelines for environmental guidelines relating to the SSA
switch installation.
The installation site must be within reach of the network cabling and meet the requirements listed
below:
Appropriate grounded power receptacles must be located within 7 feet of the site.
A temperature of between 5°C (41°F) and 40°C (104°F) must be maintained at the installation
site with fluctuations of less than 10°C (18°F) per hour.
Unpacking the SSA Switch
Unpack the SSA switch as follows:
1. Open the box and remove the packing material protecting the SSA switch.
Save the shipping box and materials in the event the unit must be reshipped.
2. Remove and set aside the RJ45-to-DB9 converter, anti-static wrist strap, adhesive feet (for flat
surface placement), and power cord retention clips.
The SSA switch does not include screws for attaching the SSA switch to rack posts.
3. Verify the contents of the carton as listed in the Table 2-1.
4. Inspect the SSA switch for any signs of physical damage.
If there are any signs of damage, DO NOT install the SSA switch; instead, contact Enterasys
Networks. Refer to “Getting Help” on page xviii for details.
Mounting the SSA Switch
Caution: To ensure proper ventilation and prevent overheating, leave a minimum clearance space
of 5.1 cm (2.0 in.) at the front and rear of the device.
Precaución: Para asegurar una buena ventilación y evitar que el sistema se sobrecaliente, deje un
espacio mínimo de 5.1 cm (2 pulgadas) con respecto el anverso y reverso del aparato.
Table 2-1 Contents of SSA Switch
Item Number
SSA chassis 1
RJ45 management cable 1
RJ45-to-DB9 converter 1
Anti-static wrist strap 1
Adhesive rubber feet 4
Power cord retention clips 2
SSA Quick Reference 1
Note: The SSA switch comes with integrated mounting ears that are adequate for most
installations. For slide-in mounting, high vibration, or high shock installations, an optional rack
mount kit (SSA-FB-MOUNTKIT) is available.
