Mounting the SSA Switch
Enterasys S-Series Stand Alone (SSA) Hardware Installation Guide 2-9
4. Repeat steps 1–3 on the other side of the chassis.
Figure 2-6 Mid-Mount Power Supply Front Configuration
Securing the SSA Switch to the Rack
To secure the SSA switch to the rack:
1. Ensure that the rack mount ears are properly installed based upon the discussion in section
“Rack Mount Ear Positioning” on page 2-6.
1 Ear mount screw removal 3 Ear mount screw insertion
2 Reposition of rack mount ear
Warning: Before rack-mounting the device, ensure that the rack can support it without
compromising stability. Otherwise, personal injury and/or equipment damage may result.
Advertencia. Antes de montar el equipo en el rack, asegurarse que el rack puede soportar su peso
sin comprometer su propia estabilidad, de otra forma, daño personal o del equipo puede ocurrir.
Warnhinweis: Überzeugen Sie sich vor dem Einbau des Gerätes in das Rack von dessen
Stabilität, ansonsten könnten Personenschäden oder Schäden am Gerät die Folge sein.
Avertissements: Avant de monter l'appareil sur le bâti, assurez-vous que l'étagère peut en
supporter le poids sans en compromettre la stabilité. Cela pourrait, dans le cas contraire, entraîner
des blessures ou des dommages au matériel.
Notes: The rack mounting ear provides three holes for securing the SSA switch to the rack. Use at
least two screws or fasteners appropriate to your rack on each side when securing the SSA switch
to the rack.
It is recommended that power supplies be installed after the SSA switch has been secured to the
rack to minimize weight that must be supported when installing rack screws.
