C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-40 Rev.1
Removing the Reduction Gear Unit
Remove the J1 Motor unit.
Remove the J1 Reduction Gear Unit.
Perform steps  to  for Removing the J1 Reduction Gear Unit of the "Joint #1 (M/C
Cable Backward)".
1
2
1
2
