Installing the Reduction Gear Unit
Install the J1 Reduction Gear Unit.
Perform steps  to  for Installing the J1 Reduction Gear Unit of the "Joint #1 (M/C
Cable Backward)".
Install the J1 Motor unit.
After assembly, perform calibration of Joint #1.
3.2 Calibration
1
2
3
2
1
