Epson SC-F2000 - Page 163

SC-F2000 Revision C
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 163
Confidential
C A U T I O N
Take care not to drop the screw B in the hole on the frame.
Hole
Screw B
C H E C K
P O I N T
When removing the screw B and screw C, insert a screwdriver in
the holes on the frame shown in the below figure.
Hole
Screwdriver
When removing the screw C
Hole
Screwdriver
When removing the screw B
