ADF/SCN ERROR (11)
 Error name
 Calibration error (error code: 190000)
 Cause
 Cannot perform proper image reading.
 Suspected cause
 CIS Module failure
 Main board failure
 FFC disconnection in ADF/SCN
 Troubleshooting
Step Check and measure Yes No
1
Visually check the FFCs of the ADF/SCN Unit.
Check the FFC (thick) in ADF/SCN that is connected to the main board to
make sure that it is not inserted obliquely or disconnected.
Go to step 2
 Properly connect the FFC of ADF/SCN.
 Replace the ADF/SCN Unit if the FFC is
damaged.
2
Replace the ADF/SCN Unit.
Does the error occur after replacing the ADF/SCN Unit?
Go to step 3 End
3
Replace the Main Board Assy.
Does the error occur after replacing the Main Board Assy?
Contact the EPSON Service Department. End
