EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 128
Confidential
ADDITIONAL CASSETTE FW ERROR (3)
 Error name
 Addition contact state error 1 (Stop IR) (error code: 032051)
 Addition contact state error 2 (except Stop_IR)
(error code: 032052)
 Cause
 Optional Cassette Unit installation failure
 Foreign object in connection part
 Drawer Connector failure
 Optional Paper Cassette Main Board Assy failure
 Suspected cause
 The connection terminal is thought to have a connection failure at the
Printer and optional cassette connection part.
 Troubleshooting
ADDITIONAL CASSETTE FW ERROR (4)
 Error name
 Addition recovery mode error (error code: 032101)
 Cause
 Occurs when the recovery mode is entered due to a failure of the
firmware update of the additional cassette.
 Suspected cause
 Firmware update is failure
 Troubleshooting
Step Check and measure Yes No
1
Check the Optional Cassette Unit installation
state.
Check that the Additional Cassette is properly
installed.
Go to step 2
Reinstall the
Optional
Cassette
Unit.
2
Check the foreign material in connection part
Check that there is no foreign object trapped in the
contact point between the main unit and the
Optional Cassette Unit.
Go to step 3
Remove the
foreign
object from
connection
part.
3
Replace the Drawer Connector.
Does the error occur after replacing the Drawer
Connector?
End
Replace the
Optional
Paper
Cassette
Main Board
Assy.
Step Check and measure Yes No
1
Update the firmware.
Check if the error is displayed even after firmware
update when the Optional Cassette has been
connected.
Replace the
Optional
Paper
Cassette
Main Board
Assy.
End

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
