ADF/SCN ERROR (4)
 Error name
 HP detection failure (error code: 100016)
 Cause
 The zero-point mark cannot be scanned.
 Suspected cause
 CIS Module failure
 FFC disconnection in ADF/SCN
 Main Board failure
 Troubleshooting
Step Check and measure Yes No
1
Visually check the FFCs of the ADF/SCN Unit.
Check the FFCs (x2) in ADF/SCN to make sure that it is not inserted
obliquely, disconnected, or damaged.
Go to step 2
 Correctly insert the two FFCs.

If FFC is damaged, replace the ADF/SCN
Unit. (Replace the unit even if one of the two
FFCs is damaged.)
2
Replace the ADF/SCN Unit.
Does the error occur after replacing the ADF/SCN Unit?
Go to step 3 End
3
Replace the Main Board Assy.
Does the error occur after replacing the Main Board Assy?
Contact the EPSON Service Department. End
