EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 121
Confidential
ADDITIONAL LIFT ERROR (1)
 Error name
 LFT2 PID driving time error (error code: 000180)
 Cause
 The drive time of the Optional LIFT Motor has exceeded a fixed value.
 Suspected cause
 Optional Cassette ASF Motor cable failure
 Optional Paper Cassette Main Board Assy failure
 Troubleshooting
Step Check and measure Yes No
1
Check the Optional Cassette ASF Motor cable.
Is the optional cassette ASF motor cable (CN13) connected properly? (Refer
to P. 592)
Go to step 2
 Correctly insert the optional cassette ASF
motor cable (CN13).
 Replace the Optional Cassette Unit in the
case of cable damage.
2
Replace the Optional Paper Cassette Main Board Assy.
Does the error occur after replacing the Optional Paper Cassette Main Board
Assy?
Replace the Optional Cassette Unit.
(If the trouble is not resolved, contact the
EPSON Service Department.)
End

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
