EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Service support mode Service Support Mode 216
Confidential
5.1 Service Support Mode
Service support mode is a service dedicated special mode that can be started by
a special operation, and allows you to execute functions including printer
inspection mode and service status sheet printing functions, etc.
5.1.1 Service mode startup
FOR WF-C5790/WF-C5790A/WF-C5710/ET-8700
1. Press and hold down the power button while pressing the [#] button from
the power-off state until a message appears on the panel LCD.
Figure 5-1. Printer Startup
Figure 5-2. ID number input screen (1)
2. Enter ID number of Service Support Mode, and start the service support mode.
Figure 5-3. ID number input screen (2)
ID number input procedure
1. Press a number input button ([2] button or [8] button) to enter a
number from 1 to 9.
2. Press the input digit shift button ([6] button) to shift to the next digit.
3. Repeat the above procedure to enter the specified ID number.
4. When all of the ID number is entered, press the execute button ([#]
button). A confirmation message appears.
5. Press the execute button ([#] button) to execute or press the input digit
shift button ([6] button) to enter the number again.
UP: [2] / DOWN: [8]
SHIFT: [6] / Fin: [#]
_
Enter “61544” when starting service support mode.
Operating procedure
• Number input (move in ascending order): [2] button
• Number input (move in descending order): [8] button
• Input digit shift: [6] button
• Execute: [#] button
It is not possible to return to the previous digit after
shifting digits. If you wish to correct the number of the
previous digit, proceed with the steps until after Step 4.
and then perform input again.
Please note that the execute button is not enabled until at
least two digits have been entered.
UP: [2] / DOWN: [8]
SHIFT: [6] / Fin: [#]
****_
