EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 129
Confidential
ADDITIONAL CASSETTE FW ERROR (5)
 Error name
 Addition communication error 1 (error code:032151)
 Addition communication error 2 (error code:032152)
 Addition communication error 3 (error code:032153)
 Addition communication error 4 (error code:032154)
 Addition communication error 5 (error code:032155)
 Addition communication error 6 (error code:032156)
 Addition communication error 7 (error code:032157)
 Addition communication error 8 (error code:032158)
 Addition communication error 9 (error code:032159)
 Addition communication error 10 (error code:032160)
 Addition communication error 11 (error code:032161)
 Addition communication error 12 (error code:032162)
 Cause
 Communication data abnormality due to noise etc.
 Occurs when changing the number of stages of additional cassettes
while the power is on.
 Suspected cause
 Drawer Connector failure
 Optional Paper Cassette Main Board Assy failure
 Main Board failure
 Troubleshooting
CSIC ERROR (1)
 Error name
 CRCM fuse blown error (error code: 033001)
 Cause
 Decline in CRCM input voltage (VHV)
 Suspected cause
 FFC disconnection in CRCM
 Short-circuiting due to oblique insertion of FFC in CRCM
 Communication failure in main board and CRCM Board
 Main Board failure
 Troubleshooting
Step Check and measure Yes No
1
Check if the error occur with turning the printer
off and on.
Does the error occur when turning the power off and
back on?
Go to step 2 End
2
Check the replacement of the Optional Cassette
Replace the Optional Cassette with a normal
product, and then check the status. No error occurs.
Go to step 3
Replace the
Main Board
Assy.
3
Replace the Drawer Connector.
Does the error occur after replacing the Drawer
Connector?
End
Replace the
Optional Paper
Cassette Main
Board Assy.
Step Check and measure Yes No
1
Visually check for the FFC of CRCM.
Check the CRCM FFC to make sure that it is not
inserted obliquely.
Go to step 2
Reconnect
the FFC that
connects the
CRCM and
the main
board.
(Replace the
FFC if it is
disconnecte
d or there
are burrs.)
2
Replace the Main Board Assy.
Does the error occur after replacing the Main Board
Assy?
Contact the
EPSON
Service
Department.
End
