Troubleshooting Troubleshooting procedure 110
Confidential
ASF ERROR (1)
 Error name
 ASF PID driving time error (error code: 000060)
 ASF load position driving time error (error code: 000070)
 Cause
 The drive time of the motor exceeded the set time.
 Suspected cause
 Motor cable disconnection or cable contact failure
 Main Board failure
 Troubleshooting
Step Check and measure Yes No
1
Visually check the status and connection of ASF Motor Cable (CN80).
Is the ASF Motor Cable (CN80) connected properly? (Refer to P. 592)
Go to step 2
 Correctly insert the ASF Motor Cable
(CN80).
 Replace the Printer Mechanism if damaged.
2
Replace the Main Board Assy.
Does the error occur after replacing the Main Board Assy?
Contact the EPSON Service Department. End

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
