Epson WF-C5790 - Inksystem

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 378
Confidential
6.2.4.14 Inksystem
OUTLINE
Part or Component
Guide
Time
Disassembly/
Reassembly
Adjustment/
Inspection
Total
Ink Eject Cover --- --- ---
Inksystem Unit --- --- ---
Maintenance Box Detect
Sensor Assy
--- --- ---
Porous Pad Cap Lower --- --- ---
A
B
C
D
