Troubleshooting Troubleshooting procedure 90
Confidential
ADF/SCN ERROR (1)
 Error name
 ADF PID excess speed detection (error code: 100001)
 Cause
 State in which driven at unexpected speed (fast) for control.
 Suspected cause
 Mechanical load error (light)
 Main Board failure
 ADF Encoder board failure
 ADF Scale is dirty or damaged.
 Troubleshooting
Step Check and measure Yes No
1
Visually check the FFCs of the ADF/SCN Unit.
Check the FFCs (x2) in ADF/SCN to make sure that it is not inserted
obliquely, disconnected, or damaged.
Go to step 2
 Correctly insert the two FFCs.
 If FFC is damaged, replace the ADF/SCN
Unit. (Replace the unit even if one of the two
FFCs is damaged.)
2
Visually check the gear train parts.
Check the gear train parts to make sure that there is no foreign object on or
damage to them.
Go to step 3
 Remove the foreign object.
 Replace the ADF/SCN Unit if the gear is
damaged.
3
Replace the ADF/SCN Unit.
Does the error occur after replacing the ADF/SCN Unit?
Replace the Main Board Assy.
(If the trouble is not resolved, contact the
EPSON Service Department.)
End
