Troubleshooting Fax Troubleshooting 171
Confidential
 Example of DCS 830042F844 FCS=83 FIF=00 42 F8 44
hex 4 4
bin 0 1 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
bit no.
32 31 30 29 28 27 26 25 40 39 38 37 36 35 34 33 48 47 46 45 44 43 42 41
bit no. DIS/DTC data Content
4 25 On hold 0
26 Uncompressed mode 0
27 Error correction mode (ECM) 1 ECM
28 Frame size 0= 256 oct 1=-64 oct 0 Frame size 256 oct
29 On hold 0
30 On hold 0
31 Encoding method (MMR T.6) 1 MMR
32 Extended field 0 Non Extended
5 33 Invalid field signal capability
34 Set to 0
35 Set to 0
36 Encoding method (T.43)
37 Plain interleave
38 32 k ADPCM audio coding (TTC JT-G726)
39 Hold for using the extended audio encoded
40 Extended field
6 41 Line density (high delicate / S-FINE) R8 x 15.4 l/mm
42 Line density(300) 300 x 300 dpi
43 Line density (Ultrahigh delicate / E-FINE) R16 x 15.4 l/mm or 400 x 400 dpi
44 Select resolution type 0: inch system resolution 1:milimater resolution
45 unused
46 unused
47 Set to 0
48 Extended field
