Troubleshooting Fax Troubleshooting 176
Confidential
03239 <- PIX FF
[33,600 bps(V.34) / MMR / A4 / 8x7.7 / 960(E:1)]
Received the 1st page of image signal.
Communication status is described within [ ].
Communication speed (Protocol) :33.6kbps (V.34)
Encoding method : MMR
Paper width : A4
Resolution : 8x7.7 (Fine)
Number of line (number of error line) : 960(E:1)
ćā An error occurs after receiving the 960th line.
06612 <- DCN FB The communication became impossible due to the error. It ended in failure by
receiving a disconnect command from the sender.
PROTOCL V.34 Displays the protocol set when starting communication (V.34/V.17/V.29)
SPEED 33.600Bps (3429) Displays the speed of the last communication.
Symbol rates are shown in ()
CODING MMR Displays the encoding method set when starting communication (MMR/MR/MH)
Table 4-4. Commands/responses log_ Sample Example (Type = Sending)
Time
(10ms)
Direction
Commands/
responses name
Data Description
To Next Page
