EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 459
Confidential
DISASSEMBLY FLOWCHART
A1
D1
B1
Start
Rear Cover (Back)
(→P. 460)
Start
ASF Front Cover
(→P. 460)
Ink Eject Cover
(→P. 461)
Housing Right
(→P. 461)
Housing Left
(→P. 462)
ADF/SCN Unit
(→P. 463)
Housing Upper
(→P. 462)
Hinge Assy
(→P. 464)
Hinge Lower Cover
(→P. 464)
A8
C1
A2
D2
B2
C2
A3
D3
B3
C3
A4
D4
B4
C4
A5
D5
B5
C5
A6
D6
B6
C6
A7
D7
B7
C7
D8
B8
C8
Rear ASF Assy
(→P. 465)
C12
Photo Interrupter
(→P. 467)
D9
B9
C9
Rear ASF Solenoid
(→P. 467)
D12
A8
Plate
(→P. 466)
D10
B10
C10
A10
Paper Feed Roller
(→P. 466)
B11C11
D11
C H E C K
P O I N T
 As for the procedure indicated by , refer to 6.2.4.4
Housing (WF-C5200 Series) (2) (p. 254) in the case of
the WF-C5200 Series, and remove the parts from the
Rear Back Cover to the Housing Top.
 The procedure indicated by is applicable only in the
WF-C5700 Series/ET-8700.

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
