Epson WF-C5790 User Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Maintenance/inspection Cleaning 584
Confidential
4. Rotate the gear of the Inksystem Assy in the direction of the arrow to move
the wiper to wiping position.
Figure 8-2. Preparation of Cleaning the Wiper
5. Clean the wiper and the cap part using the Polyester swab moistened with
pure water.
 Cleaning the wiper
Clean the top end and right side of the Wiper by moving the Polyester swab
in the direction of the arrows as shown in the figure below.
Figure 8-3. Cleaning the Wiper
Wiper
Wiper
Gear
Inksystem Assy
 If the Polyester swab is moved in a direction other than
that indicated by the arrows in the figure above, the
Wiper may shift. Therefore, always be sure to move it in
the direction of the arrows.
 Be very careful when cleaning the Wiper as it is made of
rubber and may be easily damaged.
Right
Wiper
Top
Wiper

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
