Ericsson | Antenna Line Congurator
42
9�2 Connect to an ALD
1� After pressing Connect in figure 48, section 9�1
The following page is shown:
2� After the ALC has established a connection to the ALD,
the Connect button is gray and you can view the ALD
properties and change some settings�
The following page is shown:
① Shows the ALD icon
② Shows the ALD serial number
③ Shows the vendor code and the device type
④ Opens the AISG protocol scanning options, see
section 9�1�1
⑤ Generates an ALD report
Fig� 51: Devices: Connecting to an ALD Fig� 52: Devices: Connected to an ALD
