Ericsson 86010158 - ASD Autoset Target and Thresholds; ASD Subunit Editing

Ericsson | Antenna Line Congurator
63
9�8�2 ASD Autoset Target / Delete Thresholds
① Opens the editable fields of the ASD Subunit
② Shows the ASD values
① Write the Thresholds and Target Values directly and
save the changes
② Opens the ASD Autoset Target page see 9�8�2
③ Opens the ASD Delete Thresholds, see 9�8�2
④ Save changes
Fig� 92: Devices: ASD subunit overview Fig� 93: Devices: subunit ASD edit
9�8�3 ASD Subunit
① Select the Thresholds to be deleted
② Save changes
Fig� 91: Devices: ASD Delete Thresholds
Fig� 90: Devices: ASD Autoset Target
① Select the Target values that should be set
automatically
② Save changes
