9�8�1 ASD Main Device
Tap ③ in Fig� 87 the following image is shown: Tap ① in the previous Fig, the following image is shown:
① Opens the firmware update directory see 9�4�1�2
② Opens the vendor specific file update directory see
9�4�1�2, only available with Ericsson devices�
③ Reconnects the ASD
④ Clears the Alarms
⑤ Opens the Autoset Target page see section 9�8�2
⑥ Opens the delete thresholds page see section 9�8�2
① Opens the actions of the ASD Main Device
② Shows the ASD Main Device values
Fig� 89: Devices: ASD connected with subunit
Fig� 88: Devices: ASD connected
