Ericsson | Antenna Line Congurator
49
9�5 Operate the RET
Prerequisites:
• The ALC has found the ALD�
• The ALD is connected to the ALC, see section 9�1, and 9�2
The following is shown:
1� Tap
① in Fig� 63 to open the list with the subunits�
The following page is shown:
① Opens the list with the individual subunits, see section
9�5�2
② Opens the RET properties, see section 9�5�1
③ Generates ALD reports, see section 9�3
④ Selects the AISG protocol options for reports, see
section 9�1�1
① Shows the list of the subunits
② Opens the subunit setting, see section 9�5�2
③ Opens the RET settings, see section 9�3�1
④ Selects report types and generates reports, see section
9�3
⑤ Selects the AISG protocol options for reports, see
section 9�1�1
Fig� 63: Devices: Connected to a RET Fig� 64: Devices: Configuring the RET antenna
