Ericsson | Antenna Line Congurator
56
9�7 Operate the RAE
① Opens the list with the individual subunits
② Generates ALD reports, see 9�3
③ Selects the AISG protocol scanning options
① Shows the list of the subunits
② Opens the subunit properties, see Showing Properties
of the RAE Subunits see 9�6�2
③ Opens the RAE properties, see 9�6�1
④ Selects report types and generates reports, see 9�3
The ALC has found the ALD and the ALD has been
connected to the ALC, see 9�1 and 9�2
1� Tap
① in Fig� 77� The following page is shown:
The following is displayed:
Fig� 77: Devices: Connected to a RAE Fig� 78: Devices: Configuring the RAE
