Ericsson | Antenna Line Congurator
67
Fig� 102: Sharing: Site sharing adapter information Fig� 103: Sharing: Site sharing adapter information – error
3� Tap Connect (① in Fig� 101)�
The scanning process starts� When a site sharing adapter
is found, the following page is shown:
① Selects a report type, see section 10�2
② Shows the site sharing adapter information
③ Rescans the site sharing adapter
④ Opens the site sharing adapter settings menu, see
section 10�3
⑤ Closes the page and returns to the main menu
The following error message is shown if no data exists for
the connected ALD:
4� Contact Ericsson to receive a new ALD Configuration
Data (XCD) file�
