ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05 Chapter C: System functions
Operation & Software Manual
Direct Drives & Systems 189
13.8.5.4 Mask test
13.8.5.5 Test on the value
Type 4
Activation condition
Logic operation: P2 is masked by P1 (P2 AND P1).
If the result of the operation fulfils the condition requested in P3.
Executing function Sets the bit defined in P4 to 1
Parameters Function Format
P1 Mask to apply Value Description (UD)
P2 register to test Register Description (RD)
P3
Jumps to a label (if existing) and modifies the
bit defined by P4
0: No test
1: Rising edge
2: Falling edge
3: Rising and Falling edge
4: State 0
8: State 1
+0: at least 1 bit of the mark has changed
+32: all bits of the mask have changed
P4 Bit to modify Bit Description (BD)
Type 20
Activation condition
Comparison of P1 (register) with P2 (immediate value)
If the result of the comparison fulfils the condition requested in P3.
Executing function Sets the bit defined in P4 to 1
Parameters Function Format
P1 Register to test Register Description (RD)
P2 Value of comparison Value Description (UD)
P3
Jumps to a label (if existing) and modifies the
bit defined by P4
0: No test
1: P1 > P2
2: P1 = P2
3: P1 >= P2
4: P1 < P2
5: P1 != P2
6: P1 <= P2
128: No test
129: P1 > P2
130: P1 = P2
131: P1 >= P2
132: P1 < P2
133: P1 != P2
134: P1 <= P2
edge
edge
edge
edge
edge
edge
edge
state
state
state
state
state
state
state
P4 Bit to modify Bit Description (BD)
