DSCDM monitorings
56
Time-out error in TEB communication. This error is
checked only if bit#1 of K141 is set
59
There are several nodes that have the same number on
the TEB
60
Error in homing process when leaving home switch or
limit switch. Checks K48 parameter or DIN 2, 9 or 10.
This error occurs when after the trip from K48 the home
switch or limit switch is present
61
Error in multi-index homing process. Checks K43, K44
and K75 parameters. This error occurs when the motor
has reached the two mechanical end stops (detections
are done by K43 and K44) without having finished the
homing process (for linear motors)
62
Error in single index homing process. Checks K43 and
K44 parameters. This error occurs when the motor has
reached the two mechanical end stops (detections are
done by K43 and K44) without having finished the
homing process (for linear motors)
63 Error in start synchro on input (STI command)
65
Error when the real position (M7) is out of the limits
defined by K34 and K35 when bit#1 of K36 is set
66
Error when the reference position is out of the limits
defined by K34 and K35 when bit#2 of K36 is set
67
Movement not possible because the controller is not in
power on mode
68
PWR ON not possible because the controller is in
interpolation mode (by ITP=1)
69
Homing is not possible due to the configuration of the
controller and the setting
80 Framing error on EBL2
81 Overrun error on EBL2
82 Checksum error on EBL2 message
84 Input buffer full on EBL2
85 Bad CRC on EBL2 in received message in CRC Mode
88 Other axis error on EBL2
116
This error is generated by the ERR command. In
general, this command is sent by the DSMAX or the
u-master
130
Hardware overcurrent. The current has reached the
maximum admissible value by the controller
141 Watchdog error
144
The difference between the oscillator and quartz is too
big
150 Bad measure during the phasing process when K90=1
151
Bad time measurement during phasing process when
K90=1
152
Error when the controller is disabled during phasing
process when K90 = 1 or 2
153 Too low force when K90=6
154 Too high force when K90=6
155 Too low time when K90=6
156 Time-out during AUT command
M Alias Values
Bit #
<P1>
Comment for monitorings M
and <P1> of the DSCDM
Def. Val
<P1>
Min. Val
<P1>
Max. Val
<P1>
