FieldServer LonWorks ProtoNode - Ordering Information; Protonode Detailed View

Page 52 of 97 PN: 106417-05
10.3 Ordering information
Table 10-2: ProtoNode Ordering Information
ProtoNode LER LonWorks
ProtoAir RER BACnet
Universal Gateway (Device only)
PN: 106418-01
PN: 29444-3
Universal Gateway I&O
PN: 106417-05
PN: 106417-04
Universal Gateway Enclosure Kit
(Includes device mounted inside
of a plastic enclosure and I&O)
PN: 112736-02
PN: 112736-01
Universal Gateway Wiring
Harness Kit
(Includes device installed with
AMP/BFIT 1000-4000
CTD 1250-1500
ARC/FF 1500-6000 wiring
harness and I&O)
PN: 106433-02
PN: 112316-01
10.4 ProtoNode Detailed View
Figure 10-1: LonWorks ProtoNode Detailed View
