1.2 Universal Gateway Available Configurations
The ProtoNode is shipped with the below listed configurations pre-configured and loaded. There is no
need to download any configuration. The user simply selects the configuration from a list or Auto-
Discovers the configuration.
Table 1-1: Universal Gateway Available Configurations
Application
Available Profiles
(Example:
Lon_4109)
Wiring
Section #
BACnet, N2
Points List
Section #
Type
Configuration
Discovery
EVS and EVCA Boilers with
Thermal Solutions Boiler Control
(TSBC) or
Burnham Commercial Models with
Sage Boiler Control (SBC)
TSBC
3.3
12.1
Auto-Discovery
Older Apex, Alpine, ASPEN,
Phantom-X or Raptor with
Sage 2.1 Control and Panasonic
Display
(To check software, press the “i"
button on home screen.)
4109
note1
3.4
12.2
Auto-Discovery
AMP/BFIT/Citadel/Phantom-XL 400-
1000L, Apex, Alpine, ASPEN
Phantom-X or Raptor
Sage 2.2, 2.3 Control, Concert
Control, Concert 4-inch Display or
Panasonic Display
4716
note1
3.5
12.3
Auto-Discovery
Older Arctic or FreeFlex
4716
3.6
12.3
Web-Configurator
Arctic, FreeFlex,
AMP/BFIT 1000-4000,
or Citadel 1250-1500
with Concert Control & Concert
7-inch Display and Sola
4716
3.7
12.3
Web-Configurator
Thermal Solutions and Bryan Boiler
Control System Components
RWF40
3.8
12.4
Web-Configurator
RWF55
3.8
12.5
Web-Configurator
RM7800
3.9
12.6
Web-Configurator
LMV52
Note 2
12.7
Web-Configurator
LMV36
Note 2
12.8
Web-Configurator
PD765
Note 2
12.9
Web-Configurator
LMV2_3
Note 2
12.10
Web-Configurator
YB110
Note 2
12.11
Web-Configurator
ALTA, ALTAC, Phantom II and
Phantom Combi II Control
ALTA
3.10
12.12
Web-Configurator
Conductor
Conductor_EMS
3.11
12.13
Web-Configurator
NOTE 1: Go to Delta or Panasonic screen home page, select information “i” button. Read
software version 4109 or 4716.
NOTE 2: Refer to instruction manuals supplied with boiler and control system for wiring details.
