Page 7 of 97 PN: 106417-05
2 SETUP
Each ProtoNode has a unique part number located on the underside of the unit. This number should be
recorded, as it may be required for technical support. The number is shown below:
Table 2-1: ProtoNode Part Number
2.1 Boiler Setup
2.1.1 Apex Alpine, ASPEN, Phantom-X, Raptor Boilers with Panasonic Display
On Apex Boilers with Panasonic GT02 display, using the boiler mounted display, set a unique “Boiler
Address” for each boiler that will be connected to the network.
• To change “Boiler Address” on Boiler Mounted Display; go to “Adjust” menu.
• In “Adjust” menu, enter “Sequencer Slave” menu to edit “Boiler Address”
NOTICE: For Apex boilers with a Panasonic GT02 display, all boilers must have Sequencer
Master disabled.
2.1.2 Apex, Arctic, AMP, FreeFlex, BFIT, Citadel, Phantom-XL with Concert Display
On Apex, Arctic/FreeFlex, or AMP/BFIT/Citadel/Phantom-XL boilers/water heaters with Concert Displays,
assign a unique Comm HMI Station ID for each boiler connected directly to the ProtoNode.
• To change “Comm HMI Station ID” select “Menu” on Concert Display
• On the “Main Menu” select “EMS Interface” and select “Modbus Setup”
• Select “EMS Modbus Parameter” and follow on screen instructions to edit “Comm HMI Station ID”
2.1.3 EVS and EVCA boilers with TSBC or Burnham Commercial Models with SBC
On EVS and EVCA Boilers with TSBC or Burnham Commercial models with SBC, from the
Communication Menu set the following:
Table 2-2: TSBC/SBC Communication Settings
• To edit Communication Parameters, hold the “Menu” button down until the screen changes to the
Main Menu of the TSBC/SBC
• Scroll through the main menu and select “COMMUNICATIONS” by pressing “Enter”.
• Edit Communication Parameters as needed.
Refer to the Boiler’s instruction manual for password and menu navigation instructions.
