FieldServer LonWorks ProtoNode - Honeywell RM7800

Page 66 of 97 PN: 106417-05
Actual Angular Positioning
nvoActAngPos_XXX
SNVT_count_inc_f
Burner Alarm
nvoBrnrAlm_XXX
SNVT_count_inc_f
Activation Remote Operation
nvi/nvoREM_XXX
SNVT_count_inc_f
Controller Off In Remote Setpoint
nvi/nvorOFF_XXX
SNVT_count_inc_f
Switch-On Threshold Remote
nvi/nvorHYS1_XXX
SNVT_count_inc_f
Switch-Off Threshold Down Remote
nvi/nvorHYS2_XXX
SNVT_count_inc_f
Switch-Off Threshold Up Remote
nvi/nvorHYS3_XXX
SNVT_count_inc_f
Setpoint Remote
nvi/nvoSPr_XXX
SNVT_count_inc_f
Burner Release Remote Operation
nvi/nvoRK1_XXX
SNVT_count_inc_f
Relay K2 Remote Operation
nvi/nvoRK2_XXX
SNVT_count_inc_f
Relay K3 Remote Operation
nvi/nvoRK3_XXX
SNVT_count_inc_f
Relay K6 Remote Operation
nvi/nvoRK6_XXX
SNVT_count_inc_f
Step-By-Step Control Rem Operation
nvi/nvorStEP_XXX
SNVT_count_inc_f
Angular Pos Output Remote Operation
nvi/nvorY_XXX
SNVT_count_inc_f
12.6 Honeywell RM7800
Table 12-7: Honeywell RM7800 LonWorks Points List
Point Name
Lon Name
Lon SNVT
Com Status
nvoComStatus_XXX
SNVT_switch
Flame Signal
nvoFlameSig_XXX
SNVT_count_f
Burner Cycles
nvoBrnCyc_XXX
SNVT_count_f
Burner Hours
nvoBrnHrs_XXX
SNVT_time_hour
Burner Fault Code
nvoBrnFltCod_XXX
SNVT_count_f
Initiate
nvoInitiate_XXX
SNVT_switch
Standby
nvoStandby_XXX
SNVT_switch
Purge
nvoPurge_XXX
SNVT_switch
Pilot Ignition
nvoPilotIgn_XXX
SNVT_switch
Main Ignition
nvoMainIgn_XXX
SNVT_switch
Run
nvoRun_XXX
SNVT_switch
Postpurge
nvoPostpurge_XXX
SNVT_switch
Pre-Ignition
nvoPreIgntn_XXX
SNVT_switch
Valve Proving
nvoVlvProv_XXX
SNVT_switch
Alarm
nvoAlarm_XXX
SNVT_switch
Hold
nvoHold_XXX
SNVT_switch
Lockout
nvoLockout_XXX
SNVT_switch
First Out Code *
nvo1stOutCod_XXX
SNVT_count_f
Main Valve Proof of Closure *
nvoMnVlvCls_XXX
SNVT_switch
Burner Switch *
nvoBrnrSw_XXX
SNVT_switch
Operating Control *
nvoOpCtrl_XXX
SNVT_switch
Auxiliary Limit 1 *
nvoAuxLim1_XXX
SNVT_switch
Auxiliary Limit 2 *
nvoAuxLim2_XXX
SNVT_switch
Low Water Cutoff *
nvoLoWtrCut_XXX
SNVT_switch
High Limit *
nvoHiLim_XXX
SNVT_switch
Auxiliary Limit 3 *
nvoAuxLim3_XXX
SNVT_switch
Oil Select Switch *
nvoOilSelSw_XXX
SNVT_switch
High Oil Pressure *
nvoHiOilPrs_XXX
SNVT_switch
Low Oil Pressure *
nvoLoOilPrs_XXX
SNVT_switch
High Oil Temperature *
nvoHiOilTmp_XXX
SNVT_switch
