FieldServer LonWorks ProtoNode - APEX, Amp;Bfit;Citadel;Phantom-XL, Alpine;Phantom-X, Arctic;Freeflex, Sola (4716 Profile)

Page 61 of 97 PN: 106417-05
12.3 APEX, AMP/BFIT/Citadel/Phantom-XL, Alpine/Phantom-X, Arctic/FreeFlex, Sola (4716
Profile)
Table 12-3: APEX, AMP/BFIT/Citadel/Phantom-XL, Alpine/Phantom-X, Arctic/Freeflex, Sola
LonWorks Points List
Point Name
Description
Modbus
Register
Lon Name
Lon SNVT
Burner On Off
Enable / disable burner.
1 = on, 0 = off
400,203
nvi/nvoBrnrOnOff_XXX
SNVT_switch
Demand Source
0 = Unknown
1 = No source demand
2 = Central heat
3 = Domestic hot water
4 = Lead Lag slave
5 = Lead Lag master
6 = Central heat frost protection
7 = Domestic hot water frost
protection
8 = No demand, burner switch
turned off
9 = Domestic hot water storage
11 = Warm weather shutdown
400,006
nvoDem_Src_XXX
SNVT_count_f
CH Setpoint
Status of local setpoint
410,211
nvi/nvoCH_SP_XXX
SNVT_temp_p
DHW Setpoint
Status of local setpoint
410,453
nvi/nvoDHW_SP_XXX
SNVT_temp_p
Lead Lag Setpoint
Status of local setpoint
410,546
nvi/nvoLL_SP_XXX
SNVT_temp_p
CH TOD Setpoint
Status of local setpoint
410,212
nvi/nvoCH_TOD_SP_XXX
SNVT_temp_p
CH Setpoint Source
0=Unknown,
1=Normal setpoint,
2=TOD setpoint,
3=Outdoor reset,
4=Remote control (4-20mA ),
7=Outdoor reset time of day
410,065
nvoCH_SP_Src_XXX
SNVT_count_f
Active CH Setpoint
-40 F (-40°C) to 266 F (130°C)
Setpoint determined by CH
setpoint source (register 65).
410,016
nvoAct_CH_SP_XXX
SNVT_temp_p
DHW Setpoint Source
0=Unknown,
1=Normal setpoint,
2=TOD setpoint,
5=DHW tap setpoint,
6=DHW preheat setpoint
410,081
nvoDHW_SPSrc_XXX
SNVT_count_f
Active DHW Setpoint
-40 F (-40°C) to 266 F (130°C)
Setpoint determined by DHW
setpoint source (register 81).
410,017
nvoActDHW_SP_XXX
SNVT_temp_p
LL Master Setpoint
Source
0=Unknown,
1=CH setpoint,
2=CH TOD setpoint,
3=Outdoor reset,
4=Remote control (4-20mA ),
5=DHW setpoint,
6=DHW TOD setpoint,
7=Outdoor reset time of day,
8=Mix setpoint
410,162
nvoLLMstSPSr_XXX
SNVT_count_f
Active LL Setpoint
-40 F (-40°C) to 266 F (130°C)
Setpoint determined by LL
setpoint source (register 162).
410,018
nvoAct_LL_SP_XXX
SNVT_temp_p
Supply Sensor
-40 F (-40°C) to 266 F (130°C)
410,007
nvoSupSensor_XXX
SNVT_temp_p
Return Sensor
-40 F (-40°C) to 266 F (130°C)
410,011
nvoRetSensor_XXX
SNVT_temp_p
Header Sensor
-40 F (-40°C) to 266 F (130°C)
410,013
nvoHdrSensor_XXX
SNVT_temp_p
Stack Sensor
-40 F (-40°C) to 266 F (130°C)
410,014
nvoStkSensor_XXX
SNVT_temp_p
Outdoor Sensor
-40 F (-40°C) to 266 F (130°C)
410,170
nvoOtdrSensr_XXX
SNVT_temp_p
