12.2 Older Apex, Alpine/Phantom-X and ASPEN/Raptor (4109 profile)
Table 12-2: Older Apex, Alpine/Phantom-X and ASPEN/Raptor LonWorks N2 Points List
Point Name
Description
Modbus
Register
Lon Name
Lon SNVT
Burner On Off (See Note 1)
Enable / disable burner.
1 = on
0 = off
400,203
nvi/nvoBrnrOnOff_XXX
SNVT_switch
Demand Source
0 = Unknown
1 = No source demand
2 = Central heat
3 = Domestic hot water
4 = Lead Lag slave
5 = Lead Lag master
6 = Central heat frost
protection
7 = Domestic frost protection
8 = No demand due to burner
switch turned off
9 = Domestic hot water
storage
11 = Warm weather shutdown
400,006
nvoDem_Src_XXX
SNVT_count_f
CH Setpoint (See Note 2)
Use this register to change the
boiler setpoint. valid range 79
F (26.1 C) to 191 F (88.3 C)
410,211
nvi/nvoCH_SP_XXX
SNVT_temp_p
DHW Setpoint
Use this register to change the
domestic hot water setpoint.
valid range 79 F (26.1 C) to
191 F (88.3 C)
410,453
nvi/nvoDHW_SP_XXX
SNVT_temp_p
Lead Lag Setpoint
Use this register to change the
lead lag setpoint.valid range
79F (26.1C) to 191F (88.3C)
410,546
nvi/nvoLL_SP_XXX
SNVT_temp_p
CH TOD Setpoint
Use this register to change the
central heat ‘time of day’
setpoint
valid range 79 F (26.1 C) to
191 F (88.3 C)
410,212
nvi/nvoCH_TOD_SP_XXX
SNVT_temp_p
CH Setpoint Source
0=Unknown,
1=Normal setpoint,
2=TOD setpoint,
3=Outdoor reset,
4=Remote control (4-20mA ),
7=Outdoor reset time of day
410,065
nvoCH_SP_Src_XXX
SNVT_count_f
Active CH Setpoint
-40 F (-40°C) to 266 F (130°C)
Setpoint determined by CH
setpoint source (register 65).
410,016
nvoAct_CH_SP_XXX
SNVT_temp_p
DHW Setpoint Source
0=Unknown,
1=Normal setpoint,
2=TOD setpoint,
5=DHW tap setpoint,
6=DHW preheat setpoint
410,081
nvoDHW_SPSrc_XXX
SNVT_count_f
Active DHW Setpoint
-40 F (-40°C) to 266 F (130°C)
Setpoint determined by DHW
setpoint source (register 81).
410,017
nvoActDHW_SP_XXX
SNVT_temp_p
LL Master Setpoint Source
0=Unknown,
1=CH setpoint,
2=CH TOD setpoint,
3=Outdoor reset,
4=Remote control (4-20mA ),
5=DHW setpoint,
6=DHW TOD setpoint,
7=Outdoor reset time of day,
8=Mix setpoint
410,162
nvoLLMstSPSr_XXX
SNVT_count_f
