Active LL Setpoint
-40 F (-40°C) to 266 F (130°C)
Setpoint determined by LL
setpoint source (register 162).
410,018
nvoAct_LL_SP_XXX
SNVT_temp_p
Supply Sensor
-40 F (-40°C) to 266 F (130°C)
410,007
nvoSupSensor_XXX
SNVT_temp_p
Return Sensor
-40 F (-40°C) to 266 F (130°C)
410,011
nvoRetSensor_XXX
SNVT_temp_p
Header Sensor
-40 F (-40°C) to 266 F (130°C)
410,013
nvoHdrSensor_XXX
SNVT_temp_p
Stack Sensor
-40 F (-40°C) to 266 F (130°C)
410,014
nvoStkSensor_XXX
SNVT_temp_p
Outdoor Sensor
-40 F (-40°C) to 266 F (130°C)
410,170
nvoOtdrSensr_XXX
SNVT_temp_p
4-20 mA Rem Control Input
mA value for S2 (J8-6)
parameter selectable as
(remote set point) & (remote
modulation)
400,015
nvoRemCtrlIn_XXX
SNVT_count_f
Fan Speed
Speed of the combustion air
blower in rpm
400,009
nvoFan_Speed_XXX
SNVT_count_f
Flame Signal
0.01V or 0.01μA precision
(0.00-50.00V)
400,010
nvoFlmSig_XXX
SNVT_count_f
Burner Control State
0 Initiate
1 Standby Delay
2 Standby
3 Safe Startup
4 Prepurge - Drive to
Purge Rate
5 Prepurge – Measured
Purge Time
6 Prepurge – Drive to
Lightoff Rate
7 Preignition Test
8 Preignition Time
9 Pilot Flame Establishing
Period
10 Main Flame Establishing
Period
11 Direct Burner Ignition
12 Run
13 Postpurge
14 Lockout
400,033
nvoBrnCtrlSt_XXX
SNVT_count_f
Lockout Code
Reasons for burner lockout
0 No lockout,
4 Supply high limit
5 DHW high limit
6 Stack High limit
12 Flame detected out of
sequence
18 Lightoff rate proving
failed
19 Purge rate proving failed
20 Invalid Safety
Parameters
21 Invalid Modulation
Parameter
22 Safety data verification
needed
23 24VAC voltage low/high
24 Fuel Valve Error
25 Hardware Fault
26 Internal Fault
27 Ignition Failure
410,034
nvoLockotCod_XXX
SNVT_count_f
Hold Code
Reason for burner hold
0 None
1 Anti short cycle
2 Boiler Safety Limit Open
3 Boiler Safety Limit
Open, (ILK Off)
7 Return sensor fault
8 Supply sensor fault
9 DHW sensor fault
10 Stack sensor fault
11 Ignition failure
13 Flame rod shorted to
ground
410,040
nvoHoldCode_XXX
SNVT_count_f
