FieldServer LonWorks ProtoNode - Alta;Phantom II Control

Page 73 of 97 PN: 106417-05
Aux_5
nvoAux5_XXX
SNVT_switch
Aux_6
nvoAux6_XXX
SNVT_switch
Aux_7
nvoAux7_XXX
SNVT_switch
Air_Flow
nvoAirFLo_XXX
SNVT_switch
12.12 Alta/Phantom II Control
Table 12-13: Alta/Phantom II Control LonWorks Points List
Point Name
Description
Modbus
Register
Lon Name
Lon SNVT
Central Heat
Enable/Disable
Central Heat Enable/Disable
0 = Disable
1 = Enable
This register enables single
boiler Central Heat 1 demand
and Sequencer Master Central
Heat 1 demand. This signal
does not revert to 0 if not
written.
401001
nvi/nvoCntHtEnbl_XXX
SNVT_switch
Demand Source
1 Unknown
2 Standby
3 Central Heat 1
4 Central Heat 2
5 Domestic Hot Water
6 Sequencer Control
7 CH Frost Protection
10 Warm Weather Shutdown
400100
nvoDemSrc_XXX
SNVT_count_f
CH1 Heat Demand
0=Off, 1= On
400009
nvoCH1HtDem_XXX
SNVT_switch
CH2 Heat Demand
0=Off, 1= On
400010
nvoCH2HtDem_XXX
SNVT_switch
DHW Heat Demand
0=Off, 1= On
400003
nvoDHWHtDem_XXX
SNVT_switch
Supply Temperature
-40°F (-40°C) to 320°F (160°C)
400016
nvoSupTmp_XXX
SNVT_count_f
Return Temperature
-40°F (-40°C) to 320°F (160°C)
400017
nvoRetTmp_XXX
SNVT_count_f
DHW Temperature
-40°F (-40°C) to 320°F (160°C)
400018
nvoDHWTmp_XXX
SNVT_count_f
Stack Temperature
-40°F (-40°C) to 320°F (160°C)
400020
nvoStackTmp_XXX
SNVT_count_f
Header
Temperature
-40°F (-40°C) to 320°F (160°C)
400022
nvoHdrTmp_XXX
SNVT_count_f
Outdoor
Temperature
-40°F (-40°C) to 320°F (160°C)
401728
nvoOtdrTmp_XXX
SNVT_count_f
Modbus Remote
Outdoor Temperature
*Energy Management System
may send control the outdoor air
temperature. Use this register to
change the outdoor temperature.
401000
nvi/nvoModRmOtTp_XXX
SNVT_count_f
CH Modbus Setpoint
CH Modbus Setpoint*
This setpoint is used for local
Central Heat 1 setpoint or
Sequencer Master setpoint.
Valid range 60°F (16°C) to 190°F
(88°C)
Note: When "EMS Time Out
Enable*" is enabled, setpoint
401002
nvi/nvoCHModSP_XXX
SNVT_count_f
