FieldServer LonWorks ProtoNode - Siemens LMV52

Page 67 of 97 PN: 106417-05
Low Oil Temperature *
nvoLoOilTmp_XXX
SNVT_switch
Gas Select Switch *
nvoGasSelSw_XXX
SNVT_switch
High Gas Pressure *
nvoHiGasPrs_XXX
SNVT_switch
Low Gas Pressure *
nvoLoGasPrs_XXX
SNVT_switch
Air Flow Switch *
nvoAirFLoSw_XXX
SNVT_switch
Auxiliary Interlock 4 *
nvoAuxIntlk4_XXX
SNVT_switch
Auxiliary Interlock 5 *
nvoAuxIntlk5_XXX
SNVT_switch
12.7 Siemens LMV52
Table 12-8: Siemens LMV52 LonWorks Points List
Point Name
Lon Name
Lon SNVT
Com Status
nvoComStatus_XXX
SNVT_switch
Process Value
nvoProcVal_XXX
SNVT_count_f
Flame Signal
nvoFlameSig_XXX
SNVT_lev_percent
Fuel Rate Volume
nvoFuelRtVol_XXX
SNVT_count_f
O2 Level
nvoO2Level_XXX
SNVT_lev_percent
Supply Air
nvoSupplyAir_XXX
SNVT_count_f
Flue Gas
nvoFlueGas_XXX
SNVT_count_f
Combustion Efficiency
nvoCombstEff_XXX
SNVT_lev_percent
Control Mode
nvi/nvoCtrlMode_XXX
SNVT_switch
Operating Mode
nvi/nvoOpMode_XXX
SNVT_count_f
External Setpoint
nvi/nvoExtSP_XXX
SNVT_count_f
Fuel Rate
nvi/nvoFuelRate_XXX
SNVT_count_f
Process Setpoint
nvi/nvoProcSP_XXX
SNVT_count_f
Hours
nvoHours_XXX
SNVT_time_hour
Current Lockout Error code
nvoCrntErCd_XXX
SNVT_count_f
Current Lockout Error diagnosis
nvoCrntErDg_XXX
SNVT_count_f
Current Lockout Error class
nvoCrntErCls_XXX
SNVT_count_f
Current Lockout Error phase
nvoCrntErPh_XXX
SNVT_count_f
Current Lockout Fuel
nvoCrntFuel_XXX
SNVT_count_f
Current Lockout Output
nvoCrntOutpt_XXX
SNVT_count_f
Current Lockout Date: Year
nvoCrntTPDYr_XXX
SNVT_count_f
Current Lockout Date: Month
nvoCrntTPDMn_XXX
SNVT_count_f
Current Lockout Date: Day
nvoCrntTPDDy_XXX
SNVT_count_f
Current Lockout Time of day: hours
nvoCrntTODHr_XXX
SNVT_count_f
Current Lockout Time of day: minutes
nvoCrntTODMn_XXX
SNVT_count_f
Current Lockout Time of day: Seconds
nvoCrntTODSc_XXX
SNVT_count_f
Current Lockout Startup counter total
nvoCrntStCtT_XXX
SNVT_count_f
Current Lockout Hours run total
nvoCrntHrRnT_XXX
SNVT_time_hour
Lockout Error Code
nvoLckotErCd_XXX
SNVT_count_f
Lockout Diagnostic Code
nvoLckotDgCd_XXX
SNVT_count_f
Fuel Selected
nvoFuelSel_XXX
SNVT_count_f
Firing Rate
nvoFirRate_XXX
SNVT_count_f
