FieldServer LonWorks ProtoNode - Conductor Sequencing Panel

Page 77 of 97 PN: 106417-05
12.13 Conductor Sequencing Panel
Table 12-15: Conductor Sequencing Panel LonWorks Points List
Point Name
Lon Name
Lon SNVT Type
Plant_load
nvoPlant_Ld_XXX
SNVT_count_f
EMS_Enable
nvi/nvoEMS_Enbl_XXX
SNVT_switch
EMS_Setpoint
nvi/nvoEMS_SP_XXX
SNVT_temp_p
Firing_Rate
nvoFir_Rate_XXX
SNVT_lev_percent
Active_Setpoint
nvoAct_SP_XXX
SNVT_temp_p
Master_SP_Source
nvoMstrSPSrc_XXX
SNVT_count_f
Status
nvoStatus_XXX
SNVT_count_f
Priority
nvoPriority_XXX
SNVT_count_f
Lead
nvoLead_XXX
SNVT_count_f
SYSTEM_SUPPLY
nvoSys_Sup_XXX
SNVT_temp_p
SYSTEM_RETURN
nvoSys_Ret_XXX
SNVT_temp_p
OUTDOOR_AIR
nvoOtdr_Air_XXX
SNVT_temp_p
UAI5_EMS_SETPOINT
nvoAI5EMS_SP_XXX
SNVT_temp_p
UAI7_PUMP_FEEDBACK
nvoPmp_Fdbk_XXX
SNVT_lev_percent
STEAM_PRESSURE
nvoStm_Prs_XXX
SNVT_count_f
BLR_A_SHELL
nvoBlrAShl_XXX
SNVT_temp_p
BLR_B_SHELL
nvoBlrBShl_XXX
SNVT_temp_p
BLR_C_SHELL
nvoBlrCShl_XXX
SNVT_temp_p
BLR_D_SHELL
nvoBlrDShl_XXX
SNVT_temp_p
UDO1_CONFIGURABLE
nvoUDO1_Cnfg_XXX
SNVT_count_f
UDO2_ALARM
nvoUDO2_Alm_XXX
SNVT_count_f
UDO7_BLR_D_ISOLATION_VALVE
voBlDIsoVlv_XXX
SNVT_switch
UDO8_PUMP_A
nvoPmp_A_XXX
SNVT_switch
UDO9_BLR_A_ISOLATION_VALVE
nvoBlAIsoVlv_XXX
SNVT_switch
UDO10_BLR_B_ISOLATION_VALVE
nvoBlBIsoVlv_XXX
SNVT_switch
UDO11_BLR_C_ISOLATION_VALVE
nvoBlCIsoVlv_XXX
SNVT_switch
UDO12_PUMP_B
nvoPmp_B_XXX
SNVT_switch
ALR_Press_High
nvoALR_PrsHi_XXX
SNVT_switch
ALR_Press_Low
nvoALR_PrsLo_XXX
SNVT_switch
ALR_Temp_High
nvoALR_TmpHi_XXX
SNVT_switch
ALR_Temp_Low
nvoALR_TmpLo_XXX
SNVT_switch
ALR_Return_Temp_Low
nvoALRRtTpLo_XXX
SNVT_switch
ALR_Pump_A_Fault
nvoALRPmAFlt_XXX
SNVT_switch
ALR_Pump_B_Fault
nvoALRPmBFlt_XXX
SNVT_switch
ALR_Shell_1_High
nvoALR_Sh1Hi_XXX
SNVT_switch
ALR_Shell_2_High
nvoALR_Sh2Hi_XXX
SNVT_switch
ALR_Shell_3_High
nvoALR_Sh3Hi_XXX
SNVT_switch
ALR_Shell_4_High
nvoALR_Sh4Hi_XXX
SNVT_switch
BLR1_Supply
nvoB1_Sup_XXX
SNVT_temp_p
BLR1_Return
nvoB1_Ret_XXX
SNVT_temp_p
BLR1_Stack
nvoB1_Stk_XXX
SNVT_temp_p
BLR1_CH_Mod_Rate
nvoB1_CHMdRt_XXX
SNVT_lev_percent
BLR1_Rate_Commanded
nvoB1_RteCmd_XXX
SNVT_lev_percent
BLR1_CH_Mod_Stat
nvoB1_CHMdSt_XXX
SNVT_switch
BLR1_General_Alarm
nvoB1_GenAlm_XXX
SNVT_switch
BLR1_Boiler_Pump
nvoB1_BlrPmp_XXX
SNVT_switch
BLR1_System_Pump
nvoB1_SysPmp_XXX
SNVT_switch
BLR1_Pump_Status
nvoB1_PmpSta_XXX
SNVT_switch
BLR1_Flame
nvoB1_Flame_XXX
SNVT_count_f
BLR1_State
nvoB1_State_XXX
SNVT_count_f
BLR1_Ann_Lockout
nvoB1_AnnLck_XXX
SNVT_count_f
BLR1_Ann_Hold
nvoB1_AnnHld_XXX
SNVT_count_f
ALR_BLR1SupplyHigh
nvoALRB1SpHi_XXX
SNVT_switch
