2.1.4 RWF40, LMV52, RM7800, LMV36, PD765, RWF55, LMV2_3 or YB110
Refer to the Boiler’s instruction manual for password and menu navigation instructions to make the
following settings:
Table 2-3: RWF40, LMV52, RM7800, LMV36, PD765, RWF55, LMV2_3 or YB110 Com.
Settings
Model
Port Setting
Selection
RWF55, YB110
Baud Rate
38400
RWF40, RM7800,
LMV36, LMV52,
PD765, LMV2_3
Baud Rate
19200
All
Protocol
Modbus RTU
Parity
None
Data Bits
8
Stop Bits
1
2.1.5 Settings for Conductor Sequencing Panel
On Conductor, from the Modbus/BACnet Setup menu set the following:
Table 2-4: Conductor Communication Settings
Parameter
Selection
EMS Communication
Modbus
Conductor RS485-1 Address
Between 1 and 20
EMS Baud Rate
38400
EMS Parity
None
• To edit Communication Parameters, select “Menu” from the home screen.
• On the “Main Menu” select “EMS Interface” and select “Modbus/BACnet Setup”.
• Enter the password by pressing the lock icon.
• Press the line for each parameter and enter the new selection.
• Once all parameters have been set to the correct selection, cycle power to the panel to enact the
changes.
