12 LONWORKS POINTS LIST
12.1 Thermal Solutions Boiler Control (TSBC) & Sage Boiler Control (SBC)
Table 12-1: TSBC/SBC LonWorks Points List
Point Name
Modbus
Register
Lon Name
Lon SNVT
Notes
Outdoor Air Reset Enable/Disable
00001
nvoOAResEnDs_XXX
SNVT_switch
Domestic Hot Water Priority
00002
nvoDmHtWtPri_XXX
SNVT_switch
Local/Remote
00003
nvoLoc_Rem_XXX
SNVT_switch
Remote On/Off Modbus Command
00004
nvi/nvoRmOnOfCmd_XXX
SNVT_switch
1
Spare Input (Programmable)
00005
nvoSprInput_XXX
SNVT_switch
Low Water Cutoff Switch
00006
nvoLoWtCtOff_XXX
SNVT_switch
2
Burner On/Off Switch
00007
nvoBrnOnOfSw_XXX
SNVT_switch
2
Low Water Flow
00008
nvoLoWtrFLo_XXX
SNVT_switch
2
High and Low Gas Pressure Switches
00009
nvoHiLoGsPrs_XXX
SNVT_switch
2
Operating or High Limit
00010
nvoOpOrHiLim_XXX
SNVT_switch
2
Low Combustion Air Flow
00011
nvoLoCmbArFl_XXX
SNVT_switch
2
Fuel Valve Energized
00012
nvoFlVlvEnrg_XXX
SNVT_switch
Flame Safeguard Alarm
00013
nvoFlmSfgdAl_XXX
SNVT_switch
Call For Heat (CFH)
00014
nvoCallForHt_XXX
SNVT_switch
General Alarm
00015
nvoGenAlm_XXX
SNVT_switch
4
Vent Inducer
00016
nvoVntIndcr_XXX
SNVT_switch
Boiler Pump
00017
nvoBlrPump_XXX
SNVT_switch
System Pump
00018
nvoSystPmp_XXX
SNVT_switch
Spare Output (Programmable)
00019
nvoSprOutput_XXX
SNVT_switch
State Boiler Disabled
00020
nvoStBlrDis_XXX
SNVT_switch
3
State Weather Shutdown
00021
nvoStWthShdn_XXX
SNVT_switch
3
State Lockout
00022
nvoStLockout_XXX
SNVT_switch
3
State Pump Purge
00023
nvoStPmpPurg_XXX
SNVT_switch
3
State Limit Hold
00024
nvoStLimHold_XXX
SNVT_switch
3
State Purge/Pilot Ign
00025
nvoStPrgPlIg_XXX
SNVT_switch
3
State Low Fire/Ignition
00026
nvoStLoFirIg_XXX
SNVT_switch
3
State Main Ignition
00027
nvoStMainIgn_XXX
SNVT_switch
3
State Low Fire Hold
00028
nvoStLoFrHld_XXX
SNVT_switch
3
State Boiler Running
00029
nvoStBlrRun_XXX
SNVT_switch
3
State Fan Post Purge
00030
nvoStFnPstPg_XXX
SNVT_switch
3
State Pump Cool Down
00031
nvoStPmpClDn_XXX
SNVT_switch
3
State Standby
00032
nvoStStandby_XXX
SNVT_switch
3
Annunciator Low Water Level
00033
nvoAnLoWtLvl_XXX
SNVT_switch
4
Annunciator Off Switch
00034
nvoAnnOffSw_XXX
SNVT_switch
4
Annunciator Low Water Flow
00035
nvoAnLoWtFlo_XXX
SNVT_switch
4
Annunciator Fuel Limit
00036
nvoAnnFlLim_XXX
SNVT_switch
4
Annunciator High Temp Limit
00037
nvoAnHiTmpLm_XXX
SNVT_switch
4
Annunciator Low Air Flow
00038
nvoAnLoArFlo_XXX
SNVT_switch
4
Annunciator FSG Lockout
00039
nvoAnFSGLkot_XXX
SNVT_switch
4
Annunciator Outlet Temp Fail
00040
nvoAnOtlTpFl_XXX
SNVT_switch
4
Annunciator Inlet Temp Fail
00041
nvoAnInlTpFl_XXX
SNVT_switch
4
Annunciator OA Temp Fail
00042
nvoAnOATmpFl_XXX
SNVT_switch
4
