10 PROTONODE INFORMATION
10.1 Specifications and Ordering Information
Table 10-1: ProtoNode Specifications
ProtoNode FPC-N35
Part Number
Part Number: 106418-01
FieldServer #: FPC-N35-0817
Electrical Connections
One 6-pin Phoenix connector with: RS-485 port (Tx+ / Rx- / gnd)
and Power port (+ / - /Frame-gnd)
One Ethernet 10/100 BaseT port
One FTT-10 LonWorks port
Power Requirements
Multi-mode power adapter: 9-30VDC or 12 - 24VAC
Approvals
CE Certified; TUV approved to UL 916, EN 60950-1, EN 50491-3 and CSA C22-2
standards; FCC Class A Part 15; DNP3 Conformance Tested; OPC Self-tested for
Compliance; RoHS Compliant; CSA 205 Approved; LonMark Certified
Physical Dimensions
11.5 cm L x 8.3 cm W x 4.1 cm H (4.5 x 3.2 x 1.6 in.)
Weight
0.2 kg (0.4 lbs)
Operating Temperature
-40°C to 75°C (-40°F to 167°F)
Humidity
5 - 95% RH (non-condensing)
NOTICE: Specifications subject to change without notice.
10.2 Compliance with UL Regulations
For UL compliance, the following instructions must be met when operating the ProtoNode.
• The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating
temperature range.
• The interconnecting power connector and power cable shall:
◦ Comply with local electrical code
◦ Be suited to the expected operating temperature range
◦ Meet the current and voltage rating for the FieldServer
• Furthermore, the interconnecting power cable shall:
◦ Be of length not exceeding 3.05m (118.3”)
◦ Be constructed of materials rated VW-1, FT-1 or better
• If the unit is to be installed in an operating environment with a temperature above 65 °C, it
should be installed in a Restricted Access Area requiring a key or a special tool to gain
access.
• This device must not be connected to a LAN segment with outdoor wiring.
