switches to local mode if the EMS
fails to write value every 30
seconds. When disabled EMS
only needs to write a valid
number after power up. The
default setting is disabled.
Active Setpoint
-40°F (-40°C) to 320°F (160°C)
400014
nvoActSP_XXX
SNVT_count_f
Active Sequencer
Master Setpoint
-40°F (-40°C) to 320°F (160°C)
400015
nvoActSqMsSP_XXX
SNVT_count_f
CH1 Setpoint Source
1 = Unknown,
2 = Normal setpoint,
3 = Rate Based Reset setpoint,
4 = Outdoor reset Setpoint,
5 = Remote control (4-20/0-10 or
Modbus),
6 = Outdoor boost
400034
nvoCH1SPSrc_XXX
SNVT_count_f
CH2 Setpoint Source
1 = Unknown,
2 = Normal setpoint,
3 = Rate Based Reset Setpoint,
4 = Outdoor Air Reset Setpoint,
5 = Remote control (4-20/0-10 or
Modbus),
6 = Outdoor Boost
400035
nvoCH2SPSrc_XXX
SNVT_count_f
Sequencer Master
Setpoint Source
1=Unknown,
2=Remote Modbus,
3=Remote 4-20/0-10,
4=DHW,
5=CH1,
6=CH1 Outdoor Air Reset
7=CH2,
8=CH2 Outdoor Air Reset
400036
nvoSqMstDmSr_XXX
SNVT_count_f
0-10VDC 4-20mADC
input
Diagnostic tool to troubleshoot /
confirm input signal. Resolution
1mV or 10uA 0-20.000 Vdc (0 -
30.00mAdc)
Signal shows remote set point or
remote rate, depending on
selection.
400109
nvoADCInput_XXX
SNVT_count_f
Lockout Code
See Table 12-14
400029
nvoLckotCde_XXX
SNVT_count_f
Hold Code
See Table 12-14
400028
nvoHoldCde_XXX
SNVT_count_f
CH Modbus Rate
*Use this register to drive
individual boiler firing rates. This
register is used when firing rate
control is performed by an
external building automation
system.
Range 0-100 %
Note: When "EMS Time Out
Enable*" is enabled, control
switches to local mode if the EMS
fails to write value every 30
seconds. When disabled, EMS
only needs to write a valid
401003
nvi/nvoCHModRte_XXX
SNVT_lev_percen
t
